¢Ã FEATURES
- All the parameters are controlled in digital.
- Easy handling.
- 100% duty cycle and top durability.
- Welding parameters can be memorized to max. 40 models of welding.
¢Ã SPEC
Model |
HPT-50-MW |
HPT-200-W |
HPT-300-W |
HPT-500-W |
Input voltage |
3¡Ë, 220V, 50/60Hz |
3¡Ë, 220V, 50/60Hz |
3¡Ë, 220V, 50/60Hz |
3¡Ë,220V, 50/60Hz |
Rated current(KVA) |
5 |
20 |
27 |
45 |
Rated output current(A) |
50 |
200 |
300 |
500 |
Duty cycle(%) |
50A, 100% |
200A, 100% |
300A, 80% |
500A, 60% |
Welding current(A) |
0.5~50 |
3~200 |
5~300 |
10~500 |
Welding voltage(V) |
20~40 |
20~40 |
25~45 |
25~45 |
Pilot current(A) |
1~10 |
10~50 |
15~70 |
20~100 |
Up slope current(A) |
0.5~50 |
3~200 |
5~300 |
10~500 |
Down slope current(A) |
50~0.5 |
200~3 |
300~5 |
500~10 |
Up/down slope current(sec) |
0.1~99 |
0.1~99 |
0.1~99 |
0.1~99 |
Pulse Current(A) |
0.5~50 |
3~200 |
5~300 |
10~500 |
Pulse Frequency(Hz) |
1~500 |
1~500 |
1~500 |
1~500 |
Pulse Width(%) |
1~99 |
1~99 |
1~99 |
1~99 |
Pilot gas (§¤/min,3kg/§²) |
0.1~1.0 |
0.3~3.0 |
0.3~3.0 |
0.5~5.0 |
Shielding gas |
2.0~20 |
2.0~20 |
2.0~20 |
2.5~25 |
Size(H¡¿W¡¿L) |
670¡¿400¡¿650 |
670¡¿400¡¿650 |
670¡¿400¡¿650 |
900¡¿440¡¿650 |
Weight(kg) |
35 |
45 |
45 |
0 |
Feature 1. Sensing on Gas pressure, Chilling Water flow rate, Overheat and auto stop the function accordingly 2. Welding parameters memory - model 40 3. Easy interface for automatic system |
||||
Option 1. Pilot gas and Shielding gas control - MFC 2. Water Chiller 3. Welding torch can be selected according to welding current |
||||
*
Note : The above mentioned specification may be changed for better
function
without
any warning
