¢Ã FEATURES
- This unit has features n functions that set up rolling pressure, rolling position, rolling depth, rolling speed, the number of rolling-press. It is featured to control these parameters and to set them for better quality. - The rolling parameters can e input and saved for repeat work using with NC system. The input parameters are automatically saved, so it is possible for beginner to work on this job. - Work-piece loading and unloading is done with manual; the rolling press process is automatically don. |
¢Ã SPEC
MODEL |
HGRP-3598-A |
Range to be rolling-pressed |
35 ~ 98 MC |
ROLLING SPEED |
50 ~ 400 RPM |
ROLLING CAPACITY |
15 TON/MAX |
ROLLING STROKE |
350 MM/MAX |
ROLLING SLIDE STROKE |
100 mm/MAX (SERVO MOTOR DRIVING) |
ROLLING PRESS POWER |
HYDRAULIC PUMP |
ROLLING SPEED CONTROL |
SERVO MOTOR |
CONTROL SYSTEM CONTROL |
N.C numerical CONTROL) |
Input power |
3©ª 380V 60Hz 25KVA |
¡Ø Note : The above mentioned specification may be changed for better function without any warning |
|
