¢Ã FEATURES
- This unit is for the automobile
engine valve only.
- Full automatic system including
the loading of the valve and the unloading.
- All the welding parameters are
digitized and saved with NC program; the saved data
can be taken out for repeat welding. So, the unit can
make the precise sufacing.
MODEL |
HPT-200-AA |
INPUT POWER |
3¨ª 220V, 50/60Hz, 25KVA |
WELDING CURRENT |
PILOT : 50A (100%) |
MAIN : 200A (100%) |
PPW TORCH |
HPT - 200 - A |
POWDER HOPPER |
HGPF - 300 - L |
CONTROL SYSTEM |
DIGITAL NC SERVO MOTOR CONTROL |
VALVE SPECIFICATION |
1)
HEAD DIA : ¨ª25~60mm
2)
STEM DIA: ¨ª5.5~10mm
3)
STEM LENGTH : 80~200mm
4) WEIGHT : 1Kg/MAX |
LOADING & UNLOADING |
AUTO |
|
