< WELDCAR-2000-L >
< WELDCAR-2000-H >
¡Ø Dimension Download ¡Ø
¢Ã DIMENSIONS
MODEL
HCB-2000-H/L
WEIGHT
8.4kgf
HCR-2000
BASIC UNIT
1.8m
5.2kgf
¢Ã SPEC.
WELDCAR-2000-H
WELDCAR-2000-L
RETED LOADING CAPACITY
120kgf
ALLOWABEL MOMENT
4000kg-cm
DRIVING MOTOR
DC90V, 30W
DC90V,30W
MAX MOVEMENT
2000mm/min
RAIL LENGTH
DRIVING METHOD
RACK&PINION
APPLICATION WELDING
GMAW ¡¤GTAW
GMAW¡¤GTAW
